Hioki CM4141-50 Clampmeter 2000A AC

Hioki CM4141-50 AC/DC Clamp Meter

The CM4141-50 is designed for electricians and technicians who work across both conventional AC electrical systems and modern DC applications including solar PV, battery storage and EV charging infrastructure. With a 2000A AC and 999.9A DC range in True RMS measurement, it handles virtually any field application.

Key Features

• 2000A AC True RMS / 999.9A DC current measurement
• DC current capability for solar, battery and EV applications
• Φ55 mm jaw opening for large conductors
• DC voltage up to 1000V; up to 2000V DC with P2010
• Bluetooth wireless via Z3210 adapter
• CAT IV 600V / CAT III 1000V safety rated
• Temperature measurement -40°C to 400°C
• IP20/IP54 rated, auto power off

Applications

Solar PV string current measurement, battery current monitoring, EV charging station testing, industrial plant maintenance and energy auditing. The DC current measurement capability without needing a separate probe makes this the practical choice for renewable energy technicians.
